G80 Eye Foundry Hook

G80 Eye Foundry Hooks are a special purpose hook with wide throat opening which makes them capable of fitting around many large objects that standard slings hook simply cannot accommodate. Suitable for lifting purpose and foundry applications.
Before using this hook, check whether hooks without safety latches are allowed for your particular application.

GET A QUOTE

Description

Product Features:

• Grade 80 Alloy Steel.

• Available in Clevis type.

• Painted finish.

• Working load limit permanently shown on the body.

G80 Eye Foundry Hook

Specifications

G80 EYE FOUNDRY HOOK
ITEM NO	SIZE	WEIGHT	WLL	B.L	DIMENSIONS(MM)
	MM	KG/PC	TON	TON	D	E	A	H	M	N	K	L
RL-EFH5-50	7-8	1.09	2	8	18	63.5	39	31	25.4	18	120	163
RL-EFH5-51	10	2.04	3.15	12.6	22	76	50.8	38	32.6	23	146	200
RL-EFH5-52	13	3.22	5.3	21.2	27	89	63.5	44.5	38.1	27	171	238
RL-EFH5-53	16	5.53	8	32	32	102	76	52	46	32	198	278
RL-EFH5-54	20	8.75	12.5	50	38	114.5	89	65	55	39	232	325
RL-EFH5-55	22	11.93	15	60	45	127.5	102	69	57	40	256	361
RL-EFH5-56	26	16.8	21.2	84.8	67.5	140	126	77	66	45	283	402
RL-EFH5-57	32	26.6	31.5	126	81.5	153.5	151.5	97.5	80	58	327	461
